Customizable Single-Station Dental Lab Workstation JG-J1

Overview The JG-J1 is a customizable single-station dental lab workstation designed for commercial laboratories, denture production centers, dental schools, technician training facilities and clinic in-house labs. Its standard configuration combines a stainless steel body, an engineered stone worktop and one independent built-in dust extraction system for a compact, practical workstation. The reference size is 1200 × 600 × 1050 mm (W × D × H). Dimensions, worktop height, drawer layout, body material, worktop material and electrical configuration can all be tailored to the confirmed order. Key Features Single-station layout for one dental technician or trainee. Standard stainless steel body with an engineered stone worktop. One independent built-in 370 W dust extraction system. Integrated dust inlet, acrylic shield and retractable air gun. Pressure regulating valve and gauge for connection to an external compressed-air source. LED dental technician work light; the light style can be customized. Built-in power outlet, master switch and dust extraction adjustment. Adjustable leveling feet for stable installation. Two elbow rests/armrests supplied as standard. Drawer quantity and layout configured according to the confirmed order. Standard Configuration Stainless steel main body Engineered stone worktop One independent built-in dust extraction unit One dust inlet One acrylic protective shield One retractable air gun Pressure regulating valve and pressure gauge One LED dental technician work light Built-in power outlet and control switches Adjustable leveling feet Two elbow rests/armrests Reference Specifications Model JG-J1 Workstation type Single-station dental lab workstation Reference dimensions 1200 × 600 × 1050 mm (W × D × H), customizable Standard body material Stainless steel Standard worktop Engineered stone Standard electrical supply 220 V / 50 Hz Optional electrical supply 110 V / 60 Hz and destination-specific plugs or sockets Dust extraction quantity One independent built-in system Dust extraction motor power 370 W Maximum negative pressure -9.8 kPa Maximum airflow 70 m³/h Maximum noise ≤60 dB Compressed-air requirement External source, approximately 0.55 MPa Air compressor Not included; available separately Custom Materials and Configurations Body options Stainless steel or powder-coated cold-rolled steel; custom colors available for applicable configurations Worktop options Engineered stone, stainless steel or melamine-faced panel Dimensions Width, depth, height and worktop height can be customized Storage Drawer quantity and layout can be customized Electrical Voltage, frequency, plugs and sockets can be configured for the destination market Additional equipment Turnover bins, plaster saws and a separate air compressor can be supplied as options Applications Commercial dental laboratories Denture production centers Dental schools and university laboratories Dental technician training centers Clinic in-house laboratories Training setups integrated with JingleMed phantom heads or dental simulators Training System Integration Options For dental education projects, the JG-J1 can be configured as part of a customized training station. An optional monitor can display an instructor’s live demonstration through an HDMI splitter or LAN-based distribution setup. An optional oral light can illuminate the oral cavity of a phantom head, and a camera-enabled oral light is also available for recording or demonstration requirements. The monitor, oral light, phantom head and dental simulator are optional integration components and are not included in the standard JG-J1 configuration. OEM and ODM Customization JingleMed operates its own hardware processing facility and can customize workstation dimensions, body and worktop materials, colors, drawer layouts, electrical configurations, logos, packaging and manuals according to project requirements. Monitor and oral-light integration can also be planned for compatible dental training systems. Frequently Asked Questions Can the dimensions and worktop height be customized? Yes. The listed 1200 × 600 × 1050 mm size is a reference configuration. Width, depth, overall height and worktop height can be adjusted according to the confirmed project. Which materials are available? The standard configuration uses a stainless steel body and an engineered stone worktop. A powder-coated cold-rolled steel body, custom colors, stainless steel worktop and melamine-faced panel worktop are available as options. Is the dust extraction system included? Yes. One independent built-in dust extraction system is included in the standard configuration. Is an air compressor included? No. The workstation connects to an external compressed-air source of approximately 0.55 MPa. A separate compressor can be supplied as an option. Can the electrical
